Jettyless energy transfer – the link that is no longer missing

A jettyless transfer system is floating technology that enables safe and efficient transfer of fluids such as LNG, ammonia, bio fuels and CO2 (for carbon capture and storage) between a carrier and an offshore or onshore terminal without a jetty.

The jettyless solution is prefabricated at a shipyard, eliminating the environmental impacts of the time- and resource -intensive construction of a jetty or a quay.

This jettyless innovation is changing the energy import and export landscape, making projects possible without the cost and inflexibility of traditional fixed-jetty infrastructure. Its flexibility and mobility enables energy distribution to areas previously considered infeasible due to high costs or challenging geography.

Not only does the jettyless transfer system contribute to major cost savings when compared to the traditional fixed infrastructure of jetties and quays, it also offers tremendous environmental benefits because it floats - leaving the marine environment where it operates completely untouched.

At ECONNECT Energy we believe that cleaner energy should be cheap and accessible. We make this possible by providing cost-efficient solutions to clients worldwide.

Discuss your energy project

Go Jettyless with the IQuay™ - a smarter, floating offshore transfer solution

ECONNECT Energy provides unique floating technology, enabled by our IQuay® technology. Our IQuay is a cost effective and flexible alternative to CAPEX- and resource-intensive jetty constructions, simplifying project permitting applications and responding to strict environmental regulations. The IQuay can be applied to a wide range of vessels and terminals, for loading and unloading, transferring LNG, ammonia, CO2, hydrogen or any other fluid.

IQuay™ Technical Highlights

The IQuay enables transfer of LNG or any other fluid between a vessel and storage facilities and is fully qualified by DNV GL.

Distance from shore
50 - 800 m

Environment
Sheltered to harsh conditions

Flowrate
100 - 2,500 m3/h

Transfer lines
Floating cryogenic hoses, specified to fluid type

Carrier vessel size
1,000 - 266,000 m3

Design life
25 years

We have leveraged on the Standard IQuay qualified design to develop solutions for large scale fluid import and export between ship & shore.

Distance from shore
50 - 800 m

Environment
Sheltered to harsh conditions

Flowrate
2,500 - 12,000 m3/h

Transfer lines
Floating cryogenic hoses, specified to fluid type

Carrier vessel size
Up to 260,000 m3

Design life
25 years

Bunkering offshore or in ports is possible with ECONNECT Energy's floating solutions.

Distance from shore
Up to 300 m

Environment
Sheltered conditions

Flowrate
500 - 1,000 m3/h

Transfer lines
Rigid pipe

Vessel size
All

Design life
25 years

Reduced Cost and Lead Time

Cut capital spending significantly by avoiding large river, harbour or coastal engineering and construction works.
Advanced technology and simple construction with low operational and maintenance costs.
Lighten the permit process for your energy project and cut project schedules in half.
Combined with a floating terminal, power supplies can ramp up quickly and effectively.
Ideal floating solution for areas which are environmentally sensitive.

Universal Attachment System

Robust, reliable and highly efficient connection.
Connection / disconnection in a matter of seconds.
Reduces relative motions between the IQuay platform and the vessel.
Motions, forces and holding capacity continuously monitored and interlinked to ESD system.
Attachment system is based on technology with more than two decades and 700.000 successful mooring operations to date.

Connects to a wide range of vessels

Vacuum pads engage with a flat portion of freeboard directly below the manifold position, meaning connection can be with virtually any vessel.
Large tidal variations can pose a problem for a jetty. The IQuay platform is floating and follows the carrier with the tide.
The process system on the IQuay can be sized according to flow rate requirements, thereby accommodating small- and large scale carriers, including bunkering capabilities.

Floating Flexible Hoses

Floating flexible cryogenic hoses are fully qualified by Bureau Veritas, and meets all the requirements under EN1474-2.
Triple redundant integrated leak monitoring system.
Continuous temperature measurement along the whole length of the line.
Superior insulation with ensures minimum boil-off gas generation.
Flexible cryogenic hoses can be provided from 6 to 20 inches in diameter.

Unmanned during operation - controlled remotely

All systems are remotely monitored and operated from the onshore control room.
Full overview of the process flow parameters and status of all main systems onboard.
Complete CCTV coverage of the platform deck areas provides the operator onshore with eyes on the platform.
Manning is only required during connection to and release from the carrier vessel, whereby crew is supplied from the tugboat.

Mooring System

Standard Multi Buoy Mooring (MBM) berths for mooring of the LNG carrier.
The IQuay platform is moored with a few mooring buoys in idle condition.
The number of mooring buoys can be between 2 and 8, depending on carrier size and metocean conditions at the project site.
The mooring buoys are equipped with quick release hooks for safe and efficient cast off.
Highly suited to areas of environmental sensitivity due to limited impact to the seabed.

Roughly 15-25hrs for loading and discharge

Process system will be sized according to the flow rate requirements of the client.
The time frame for loading and discharge is roughly 15-25 hours depending on the scale of the application.

Fully redundant ballast system

The ballast system enables the unit to follow the carrier vessel vertically during loading and unloading.
Remotely operated by the operator onshore.
100% redundancy ensures that any single failure event does not delay the operation.

Operational in significant wave height of 2 meters

The platform is optimised for minimum wave response, with extensive numerical and experimental modelling and research.
The vacuum attachment system further reduces motions when attached to the carrier vessel.

Power and signals via umbilical

A robust flexible floating umbilical provides power, signals and communication to the IQuay platform.
The umbilical runs parallel to the floating hoses, and can be reeled.
The IQuay platform is equipped with a UPS, which will keep critical systems live in case of loss of power from shore.

Minimum boil-off gas generation

Due to the superior insulation properties of the floating hoses, the boil off generation throughout the system is minimal.
Rigid piping and valves on the platform are also insulated to further reduce heat inleak.

Focus on Safety

The platform is equipped with an industry standard ship-shore-link system, which interlinks the ESD systems of the carrier vessel, the IQuay platform, and the terminal.
Fire, smoke and gas detectors are located throughout the unit, which will instantly trigger ESD and shut down process flow.

Talk to us about your project

Learn more about Jettyless Transfer

Traditional Jetty vs Jettyless

We take a look at traditional LNG import and export infrastructures and explain why jettyless can enable energy projects across the globe.

LNG Terminals

With several different types of terminal configurations, we give you the knowledge to secure the most competitive solution.

Floating Transfer Solutions

Energy sustainability and conservation of marine biodiversity are key to a healthier future. Learn more about what floating transfer solutions can accomplish.

A selection of our customers and industry partners

With proprietary technology suitable for ammonia, CO₂, hydrogen, LNG, and more, ECONNECT Energy is engaged in international projects:

Serving the upstream, midstream, downstream and bunkering sectors;
Decarbonising shipping, power generation and mobility;
Where affordable and agile solutions are required;
In environmentally and socially fragile areas with low-footprint technology.

We are dedicated to fulfilling your project goals and de-risking your marine infrastructure

ECONNECT Energy was founded to address the challenges and inefficiencies of traditional LNG offloading methods from ship to shore. Our core offerings remove the need for fixed and permanent infrastructure, such as quays, jetties, trestle structures and loading platforms, and our technology also transfers ammonia and liquid CO₂.
‍
Dredging and marine construction, which are both expensive and damaging to coastal areas, can be eliminated with ECONNECT Energy’s floating jettyless transfer solution.
